58
Agere Systems Inc.
User Manual
April 2001
Advanced Operational Mode
497AE and 1215E Boundary-Scan Master 2
Appendix B—BSM2 Register Descriptions (continued)
BSR: BIST Signature Register
Purpose
Provides the signature analysis resource for random logic BIST.
Addresses (Octal)
17—16
Note:
The address for this register in the 497AA Compatibility Mode is octal 57 (binary 1X1111).
Format
Default (Hex)
BSR = uninitialized
Read-only Bits
BSR[31:00]
Description
RLSIG[19:0] (Random Logic BIST Signature Bits)—At the conclusion of execution of random logic BIST, RLSIG
contains the resulting test signature. When random logic BIST is initiated, RLSIG[19:0] is automati-
cally initialized.
If the random logic BIST passes, the value in the BSR will be 000BDB3A (hex). The presence of any
other value in the BSR at the termination of random logic BIST indicates a logic failure in the BSM2.
Control of execution of random logic BIST and detection of the completion of execution are managed
through the BIST_IE, RL_DONE, RLSKIP, and XECBIST bits in the CBIST register.
31—20
19—00
unused RLSIG[19:0]
