参数资料
| 型号： | 420-1/2"X36YD |
| 厂商： | 3M |
| 文件页数： | 2/3页 |
| 文件大小： | 0K |
| 描述： | TAPE LEAD FOIL 1/2" X 36YD |
| MSDS 材料安全数据表： | 420 Lead Foil Tape |
| 标准包装： | 18 |
| 系列： | 420 |
| 胶带类型： | 引线箔片 |
| 胶合剂： | 橡胶 |
| 背衬，载体： | 引线箔片 |
| 厚度： | 0.0068"（6.8 mils，0.173mm） |
| 厚度 - 胶合剂： | 0.0021"（2.1 mils，0.053mm） |
| 厚度 - 背胶，载体，衬垫： | 0.0047"（4.7 mils，0.119mm） |
| 宽： | 0.50"（12.70mm）1/2" |
| 长度： | 108'（32.9m）36 码 |
| 颜色： | 银 |
| 使用： | 电子导电 |
| 温度范围： | -60 ~ 225°F（-51 ~ 106°C） |
| 包装： | 散装 |
| 其它名称： | 00021200049217 02120004921 70006147907 |
3M ? Lead Foil Tape
420 (Linered) ? 421
Features
? Very good conformability.
? Good thermal properties and will perform over a wide variety of temperature
conditions (-60° to 225°F or -54° to 106°C). It has been used at higher
temperatures for shorter duration.
? Electrically and thermally conductive.
? Can be die-cut into specific shapes.
? This material when disposed of separately is classified as RCRA hazardous waste.
Please consult applicable Federal, State and local regulations for proper disposal.
? Elevated lead levels in water may result from long term submersion of this product.
? Best results are obtained when applied to a clean dry surface above 32°F (0°C).
Also, by “feathering” the edges – rubbing the tape down with a smooth-edged
plastic piece (or similar object) – the tape can be made to better conform to the
substrate. This is especially important if the tape is to be used as a “thief” in
electroplating where the edges must fully contact the metal base.
Application Ideas
? Electroplating
? Radiation barrier
? Moisture barrier
? Chemical milling
? X-ray plate masking
? Maskant during paint stripping
? Add weight (balance) to equipment parts
(golf clubs, tennis rackets, etc.)
Disposal and Safety
Considerations
Storage
Shelf Life
? Wear protective gloves and/or wash hands after working with tape.
? Lead will slowly leach into water when submerged. Leaching will accelerate as
acidity increases.
? This material when disposed of separately is classified as RCRA hazardous waste.
Please consult applicable Federal, State and local regulations for proper disposal.
Store under normal conditions of 60° to 80°F (16° to 27°C) and 40 to 60% R.H. in
the original carton.
To obtain best performance, use this product within 18 months from date of
manufacture.
-2-
