参数资料
| 型号： | 1205 1" |
| 厂商： | 3M |
| 文件页数： | 2/2页 |
| 文件大小： | 0K |
| 描述： | TAPE POLYIMIDE HI-TEMP 1"X36YDS |
| MSDS 材料安全数据表： | 42, 1205 MSDS |
| 特色产品： | Electromagnetic Compatible (EMC) Products |
| 标准包装： | 9 |
| 系列： | 1205 |
| 胶带类型： | 绝缘高温 |
| 胶合剂： | 丙烯酸 |
| 背衬，载体： | 聚酰亚胺 |
| 厚度： | 0.0030"（3.0 mils，0.076mm） |
| 厚度 - 胶合剂： | 0.0020"（2.0 mils，0.051mm） |
| 厚度 - 背胶，载体，衬垫： | 0.0010"（1.0 mils，0.025mm） |
| 宽： | 1.00"（25.40mm） |
| 长度： | 108'（32.9m）36 码 |
| 颜色： | 琥珀 |
| 使用： | 绝缘，高温 |
| 温度范围： | 311°F（155°C） |
| 包装： | 散装 |
| 产品目录页面： | 549 (CN2011-ZH PDF) |
| 其它名称： | 1205 1 1205 1-ND 1205 X 1" 3M1205B 80610876288 Q1725476A |
3M? Polyimide Film Electrical Tape 1205
Typical Properties
Not for specifications. Values are typical, not to be considered minimum or
maximum. Properties measured at room temperature 73°F (23°C) unless otherwise
stated.
> 1 x10 Ohms
Physical Property (Test Method)
(ASTM D1000 unless noted)
Color
Adhesive
Backing Thickness
Overall Thickness
Tensile Strength
Elongation (% at break)
Electrolytic Corrosion Factor
(3M internal test method)
Adhesion to Steel
Comparative Tracking Index
(IEC Method 112)
Printable
Dielectric Breakdown
Insulation Resistance
Typical Value
US units (metric)
Amber
Acrylic
1.0 mils (0,025 mm)
3.0 mils (0,076 mm)
30 lbs / inch width (53 N / 10 mm)
55% minimum
1.0
35 oz / inch width (3,8 N / 10 mm)
CTI Group IIIb
No
> 7,500 V
6
Shelf Life & Storage
Availability
This product has a 5-year shelf life from date of manufacture when stored in a
humidity controlled storage (10°C/50°F to 27°C/80°F and <75% relative humidity).
Please contact your local distributor; available from 3M.com/electrical [Where to Buy]
or call 1-800-676-8381.
3M is a trademark of 3M Company.
Important Notice
Warranty; Limited
Remedy; Limited
Liability
All statements, technical information, and recommendations related to 3M’s products are based on information
believed to be reliable, but the accuracy or completeness is not guaranteed. Before using this product, you must
evaluate it and determine if it is suitable for your intended application. You assume all risks and liability associated
with such use. Any statements related to the product, which are not contained in 3M’s current publications, or any
contrary statements contained on your purchase order, shall have no force or effect unless expressly agreed upon,
in writing, by an authorized officer of 3M.
This product will be free from defects in material and manufacture at the time of purchase. 3M MAKES NO OTHER
WARRANTIES INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE. If this product is defective within the warranty period stated above,
your exclusive remedy shall be, at 3M’s option, to replace or repair the 3M product or refund the purchase price of
the 3M product. Except where prohibited by law, 3M will not be liable for any indirect, special, incidental or
consequential loss or damage arising from this 3M product, regardless of the legal theory asserted.
3 M
Electrical Markets Division
6801 River Place Boulevard
Austin, TX 78726-9000
800.676.8381
Fax: 800.828.9329
www.3m.com/oem
Please recycle
? 3M 2013 All rights reserved
78-8124-4706-4 Rev C
Page 2 of 2
