Development Systems Ordering Guide
MPLAB ? PM3 Universal Device Programmer
The MPLAB PM3
Universal Device
Programmer is easy-to-
use and operates with a
PC or as a stand-alone
unit, and programs
Microchip’s entire line of
PICmicro ? devices, as
well as the latest
dsPIC30F DSC devices. The MPLAB PM3 features a
large and bright LCD unit (128 x 64 pixels) to display
easy menus, programming statistics and status
information.
The MPLAB PM3 Programmer has exceptional
programming speed to allow high production
throughput, especially important for large memory
devices, and includes a Secure Digital/Multimedia Card
slot for easy and secure data storage and transfer.
The MPLAB PM3 Programmer is designed with
40 programmable socket pins, allowing each socket
module to be configured to support many different
devices, requiring fewer socket modules to support the
entire line of Microchip parts. The socket modules use
multi-pin connectors for high reliability and quick
interchange. An adapter allows current PRO MATE ? II
Device Programmer socket modules to be used on the
MPLAB PM3 Programmer.
When connected to a PC-host system, either via a
serial or USB port, the MPLAB PM3 Programmer is
seamlessly integrated with the MPLAB Integrated
Features
? RS-232 or USB interface
? Integrated In Circuit Serial Programming? (ICSP?)
interface
? Fast programming time
? Three operating modes:
- PC Host mode for full control
- Safe mode for secure data
- Stand-Alone mode for programming
without a PC
? Complete line of interchangeable socket modules to
support all Microchip devices and package options
(sold separately)
? SQTP SM serialization for programming unique serial
numbers while in PC Host mode
? An alternate DOS command-line interface is
available for batch control
? Supports PRO MATE II Device Programmer socket
modules via adapter (sold separately)
? Large easy-to-read display
? Field upgradeable firmware allows quick new device
support
? Secure Digital (SD) and Multimedia Card (MMC)
external memory support
? Buzzer notification for noisy environments
MPLAB ? PM3 Universal Device Programmer
Contents
Development Environment (IDE) providing an
exceptionally user-friendly interface for the ultimate
control during programming. The MPLAB IDE includes
a full-featured macro assembler, powerful software
simulator with symbolic debugger, color-coded
programmer’s editor, project manager, high-level
language debugging and support for Microchip and
selected third party development tools, including
compilers, low-cost in-circuit debuggers and
full-featured in-circuit emulators.
Ordering Information:
?
?
?
?
?
?
?
MPLAB PM3 Programming Unit
Serial Cable for RS-232 PC Connection
USB Cable for USB PC Connection
ICSP Cable
Power Supply And Power Cables
MPLAB Integrated Development Environment CD
User’s Guide and Technical Documentation on CD
DV007004
AC164350
DS51444
MPLAB ? PM3 Universal Device Programmer
PRO MATE ? II Device Programmer to MPLAB ? PM3 Socket Module Adapter
“MPLAB ? PM3 Universal Device Programmer Product Overview” (Available at: www.microchip.com)
DS30177T-page 48
? 2005 Microchip Technology Inc.
